Weatherproof Power Supply
Features:
- Voltage input: AC 180 - 265V
- Voltage output: DC24V
- Power output: 350W
- AC input range can be switched by a switch
Can withstand 300VAC surge input for 5 seconds
Protection types: short circuit / overload / overvoltage / overtemperature with a DC fan for forced air cooling and fan on/off control
1U low form factor
Can withstand 5G vibration test
Power-on LED indicator light
Remote shutdown with low power consumption during idle <0.75W
100% full load aging test
Operating temperature can reach up to 70℃
Operable at an altitude of 5000 meters (Note 8) High efficiency, long lifespan and high reliability 3-year warranty
Description:
The LRS-350 series is a 350W single-output enclosed power supply. It features a 30mm compact design and accepts either 115VAC or 230VAC input (selected via a switch). The entire series offers voltages of 3.3V, 4.2V, 5V, 12V, 15V, 24V, 36V and 48V. With an efficiency of up to 89%, the built-in long-life fan enables the LRS-350 to operate at full load within a temperature range of -25°C to +70°C. It has extremely low idle power consumption (less than 0.75W), making it easy for the end system to meet international energy requirements. The LRS-350 has complete protection functions and anti-5G vibration capability; it complies with the UL60950-1 international safety regulations. The LRS-350 provides a cost-effective solution for various industrial applications.
